Paper Film High-speed Servo Packing Machine CCP-HPZS220

Specifications

Model CCP-HPZS220
Film Width (Max.) 220mm
Bag Length 60-1000mm
Bag Width 30-90mm
Product Height 5-35mm
Film Roll Diameter (Max.) 300mm
Packing Speed 20-200bag/min
Packing Film paper film
Power Condition 220V,  50/60HZ,  2.9KW
Overall Dimensions (L)4115*(W)830*(H)1400mm
Weight 480kg

Feature

1. Servo control, bag length can be set and cut in one step, time-saving and film-saving.

2. Colorful touch screen control with easy parameter setting, and up to 40 kinds of packing parameters could be stored.

3. Failure can be displayed clearly by having the function of failure self-diagnosis.

4. Tracking with high-sensitivity photoelectric detector, and it leads to a more accurate cutting & sealing position with numerical input.

5. Mid-sealing wheels heating & special heating mechanism for cutting make the sealing more firm and aesthetic.

6. Positioning stop function, without sticking to blade or wasting packing film.

7. Simple driving system, more reliable and more convenient maintenance.

8. Cutters reversing automatically when product is being cut and directly run the machine after reboot, easy operation.

9. Machine automatically stops when packing film runs out.

10. Without forming mechanism makes the paper packing film flat and no crease

Application

The equipment can be applied to all kinds of toys, printing products, commodity, hardware fitting, stationery, electronic components such as tumbler, beans, toothbrush, soap, toothpaste, adapter.

attention

these are standard type of machine
we offer custom service according to your special requirements

L-type packing machine for book

L-type packing machine for vegetables with lunch box

L-type packing machine for frozen fish

L-type packing machine for sewing thread

L-type packing machine for lunch box
