How to choose Shrink Wrap Machine
The dimensions of cutting knife for L sealer packing machine as below:
| Type | Cutting Knife Dimensions (frontXside） |
| CCP-L500/CCP-L500S | 510X670mm |
| CCP-L501 | 510X900mm （actual：510X880mm) |
| CCP-L502/CCP-L502H | 750X850mm |
How to chose the machine
According to the packaging size ,the calculation formula is as follows:
Side cutting Length>product length+product height +1/2height of product
Front cutting Length>Product width+product height+1/2height of product
Example：The width of the product is 350mm,Height is 150mm, length is 450mm,which machine we should chose?
Answer：The front knife should >(350+150)+150/2=575mm
The side cutting knife should >(450+150）+150/2=675mm
So according to the calculation formula ,and the dimensions on the table,we can reach a decision: Type CCP-L502H is ok for that products packaging.
The feature of CCP-L500S and CCP-L502H
1.The L500S is with telescopic full automatic sealing machine,is suitable for the smaller products,There is a 4-5cm gap under the cutting knife,for the products which the base between 5-6cm,we suggest using CCP-L500S.Because the plane of the product is too small,so the stability is very low, we need use the telescopic to adjust the position of the product during the conveying process.
2.The L502H shrink wrap machine is main to the higher package products,Generally ,the height do not more than 200mm,because if the height is too high,we should chose the straight up and down Cutting knife.
